Our research complies with all relevant ethical regulations and was approved by the Colorado State University Institutional Animal Care and Use Committee (ref. no. 5172; efficacy studies) or the Merck Institutional Animal Care and Use Committee (PK studies).
Antibacterial assays
Mtb-GFP was cultured in 7H9/glucose/BSA/tyloxapol media until the culture reached an OD650 of 0.3 and was then diluted in 7H9/glucose/BSA/tyloxapol media at 1,000-fold for the assay. 7H9/glucose/BSA/tyloxapol media consists of: 4.7 g Difco Middlebrook 7H9 broth, 4 g glucose, 0.81 g sodium chloride, 5 g BSA, fraction V and 0.5 ml tyloxapol, brought up to a 1-l total volume with double-distilled water. For the assays, an initial inoculum of approximately 20,000 Mtb-GFP cells was used per well. Mtb-GFP cells were then exposed to a 2-fold dilution series of MK-7762 in duplicate from 50 to 0.049 μM. MK-7762 was diluted as 2 μl of 10 mM compound stock solution in DMSO added to 200 μl 7H9/glucose/BSA/tyloxapol media to produce a 100 μM concentration (2×, before adding to cells). Using a multichannel pipettor, 50 μl was transferred to each subsequent row starting with row 1 and ending with row 11. The final extra 50 μl was discarded from row 11. MK-7762 was titrated from 50 μM to 0.049 μM. Assay plates were incubated for 7 days at 37 °C, and then evaluated for GFP signal using an Envision Multimode Plate Reader (PerkinElmer). The concentration of MK-7762 that resulted in 95% growth inhibition as measured by the fluorescence signal of the Mtb-GFP assay wells compared to the drug-free control wells was recorded as the MIC95. The concentration of MK-7762 that resulted in 95% growth inhibition as measured by the fluorescence signal of the Mtb-GFP assay wells compared to the no-drug control wells was recorded as the MIC95. There was no curve-fitting for the analysis, and only values corresponding to actual test concentrations were returned as results. The cholesterol-containing media assay was run with the same protocol but substituting cholesterol for glucose.
MBC assay
H37Rv was grown to an OD650 of 0.2 in 7H9/ADC/Tw media (composition above but with 0.5 ml Tween 80 instead of tyloxapol) The cell suspension was filtered through a 5-µm filter to create a single-cell suspension and diluted 10-fold in 7H9/ADC/Tw media. A sample of the cell suspension was appropriately diluted and plated on 7H11-OADC agar to enumerate CFUs. An equal volume of the cell dilution (0.5 ml) was added to an equal volume of 7H9/ADC/Tw media containing different concentrations of oxazolidinones (MK-7762 and linezolid at 0 µM, 6.25 µM, 12.5 µM, 25 µM, 31.3 µM, 50 µM, 62.5 µM and 125 µM) in triplicate in sterile 24-well plates. Rifampicin at 0.4 µg ml−1 was used as a positive control. Plates were incubated at 37 °C, shaking at 100 rpm for 7 days after which appropriate dilutions of cells were plated on 7H11-OADC agar for CFU enumeration. 7H11-OADC agar plates were incubated at 37 °C for 4 weeks before colonies were counted.
FOR determination
H37Rv was grown to an OD650 of 0.2 in 7H9/ADC/Tw media and cells were harvested by centrifugation. Cell suspensions of 1 × 1010, 1 × 109 and 1 × 108 CFUs per milliliter were made in 7H9/ADC/Tw media of which 0.1-ml volumes were plated on 7H11-OADC agar containing different concentrations of linezolid or MK-7762 (2.5 µM, 4 µM, 5 µM, 8 µM, 10 µM and 16 µM). Each cell suspension was plated in duplicate on each drug concentration. Appropriate dilutions of cells were plated on drug-free 7H11-OADC agar plates to enumerate inoculum cell densities for FOR calculations. 7H11-OADC agar plates were incubated at 37 °C for 4 weeks before colonies were counted. Colonies that grew up on drug-containing plates were picked and MIC determination performed as described above to determine the level of resistance.
Analysis of rv3161c mRNA expression in MK-7762-resistant mutants
Wild-type H37Rv and three MK-7762 resistant mutants with Rv3160c mutations (A1, A3 and A6) were grown in 7H9/ADC/Tw media to an OD650 of 0.2 at which stage cells were harvested, resuspended in TRIzol (Thermo Fisher) and RNA isolated and treated with DNase as previously described. This was repeated to generate independent replicates for each strain. RNA was reverse transcribed with the iScript Advanced cDNA synthesis kit for RT–qPCR (Bio-Rad) following the manufacturer’s recommendations with the additional inclusion of primers for specific reverse transcription of sigA and rv3161c (sigA GCTAGCTCGACCTCTTCC; rv3161c GAGCACGTGGTAGTTCTC). Levels of sigA and rv3161c in the cDNA samples were determined by qPCR using the iTaq Universal SYBR Green Supermix (Bio-Rad) with standard curve of Mtb genomic DNA according to the manufacturer’s instruction using the sigA (sigA-F: CGGTGATTTCGTCTGGGATG; sigA-R: TTGCCGATCTGTTTGAGGTAG) and rv3161c (rv3161c-F: TGGAATGGATTGGTGTGGATC; rv3161c-R: TTCCAATTAGCTCGCCACTC) respective primers. The gene for rv3161c expression was normalized to sigA levels for each sample.
Mitochondrial biogenesis assay
The assay was performed using the MitoBiogenesis In-Cell ELISA Kit (Abcam). HepG2 cells (American Type Culture Collection, HB-8065) cultured in DMEM, 4.5 g l−1 D-glucose, 4 mM L-glutamine 10% FBS and 1 mM sodium pyruvate from T175 flasks of approximately 60% confluency were removed from flasks using 0.05% Trypsin-EDTA and combined in 10 ml of the same medium. Cells were sieved with a 40-μm cell strainer to reduce clumps and then counted at least four times using the Cellometer Auto 2000 (Nexcelom, PerkinElmer) with the counts averaged. The HepG2 cells were then seeded in a Collagen I Coated Plate (3,500 cells per well) in 170 μl of media per well and left to adhere for 16 h to 18 h at 37 °C and 5% carbon dioxide.
Serial dilutions of compounds were prepared by pipetting 177 μl of media into column 1 of a non-assay/non-culture plate (Non-Tissue Culture Treated Plate) and 90 μl of media into column 2. Compounds were added as 12.3 μl of 40 mM solutions into column 1 for a final concentration of 0.6667 mM. Linezolid was included as a positive control. Compounds were diluted serially (1:2) by pipetting 90 μl from column 1 to column 2 through to column 10. Column 11 was designated the control without compounds, and column 12 was the control without primary antibody for background signal subtraction.
Once the cells were approximately 15% confluent (day 2), the assay was initiated. Each compound (30 μl) was added from the compound plate into 170 μl of HepG2 cells (attached for 16 h to 18 h) in duplicate. The final concentration in column 1 was, therefore, 0.1 mM for each compound. Cells were cultured for an additional 72 h, or approximately three replication cycles.
On day 5, once cells cultured without compounds were approximately 70% confluent, the assay medium was removed and 4% paraformaldehyde (100 μl per well) added. Plates were incubated for 20 min. The paraformaldehyde was removed and cells were washed three times with PBS (200 μl per well per wash). PBS was removed and 0.5% acetic acid (100 μl per well) was added. Plates were incubated for 5 min. Acetic acid was removed and cells washed once with PBS (200 μl per well). PBS was removed and 0.1% Triton X-100 (100 μl per well) was added; plates were incubated for 30 min. Triton X-100 was removed. Blocking buffer (2 ×; 200 μl per well) was added and plates were incubated for 2 h. Blocking buffer was removed. Primary antibody solution (100 μl per well) was added to columns 1–11, while 1 × blocking buffer was added to column 12. Plates were incubated for 16 h to 18 h at 4 °C.
On day 6, primary antibody was removed and cells were washed three times with PBS containing 0.1% Triton X-100 (PBS-T; 300 μl per well per wash). PBS-T was removed, secondary antibody solution (100 μl per well) was added, and plates were incubated for 1 h. Secondary antibody solution was removed and cells were washed four times with PBS-T (300 μl per well each wash). PBS-T was removed and alkaline phosphatase development solution was added (100 μl per well). Plates were incubated at room temperature for 15 min; the endpoint was immediately measured at OD405 using the FLUOstar OPTIMA plate reader (BMG LabTech).
To complete the assay, alkaline phosphatase development solution was removed and horseradish peroxidase development solution (100 μl per well) was added. Plates were incubated for 15 min; the endpoint was immediately measured at OD595 using the FLUOstar OPTIMA plate reader. Horseradish peroxidase development solution was completely removed and 1× Janus Green stain (50 μl per well) was added. Plates incubated for 5 min and then washed with five times (300 μl per well) with distilled water. The water was removed and 0.5 M hydrochloric acid added (100 μl per well) to stop the reaction. Plates were incubated for 10 min with shaking at 120 rpm. The Janus Green B endpoint was measured at OD595 using the FLUOstar OPTIMA plate reader.
COX1 signal is first subtracted by the background signal. The background signal was designated as plate column 12, which was not exposed to primary antibodies. The resulting COX1 signal is then divided by the JG background-subtracted signal. COX1/JG is then divided by the values from untreated cells and multiplied by 100 to calculate the percentage COX1/JG.
Percentage response = [concentration compound] μM COX1 ratio / 0 μM COX1 ratio × 100
Using GraphPad Prism (GraphPad), the percentage ratio against the log of the compound concentration was graphed and the EC50 concentration then extrapolated where the trend curve intersected the 50% ratio using a standard four-parameter fit.
Preparation of MK-7762 stalled ribosome complex
Two liters of M. smegmatis was cultured to an OD600 of 0.5 in 7H9 medium. Cells were washed, centrifuged and cryo-lysed using a Retsch Mixer Mill 400. Lysate was applied to a 1.1-M sucrose cushion and centrifuged for 1 h and 45 min at 310,000g using a Ti-70 rotor. The pellet was resuspended and purified on a 5−50% sucrose gradient at 164,000g for 2.5 h using a SW 41 Ti rotor. Fractions were recovered using a Beckman Coulter Fraction Recovery System, and absorbance at 260 nm was recorded for each fraction. Fractions corresponding to 70S ribosomes were combined and ultrafiltered using a 10-kDa molecular-weight cutoff an Amicon Ultra Centrifugal Filter to concentrate ribosomes and exchange buffers. Stalled ribosome–drug complexes were generated using a PURExpress ∆ Ribosome kit with MK-7762, purified ribosomes, RNase inhibitor and DNA stalling template. The ribosome–drug complex was re-isolated as previously described16 through a sucrose gradient, fractionation and ultrafiltration. Purified stalled ribosome complexes were incubated for 1 h at 4 °C with 60 µM MK-7726. Before freezing to grids, the sample was filtered through a Millipore low-binding Durapore PVDF 0.22-µm filter for 5 min at 14,000g.
Cryo-EM
A standard workflow was followed for the cryo-EM sample preparation and grid vitrification. Data were collected on a Krios G4 transmission electron microscope (Thermo Fisher Scientific) with a K3 camera and a Biocontinuum GIF and processed in cryoSPARC25. M. smegmatis ribosome structure (PDB 5O61) was docked into the cryo-EM map in ChimeraX26. Models were built in COOT27 and refined in PHENIX28. Details are provided in the Supplementary Information. Figures were made with ChimeraX and PyMOL (The PyMOL Molecular Graphics System, version 3.0 Schrödinger).
Before freezing, the stalled ribosome complexes were filtered for 5 min at 12,000 at 4 °C using a 0.22-µm low-binding Durapore PVDF filter (Millipore). Quantifoil 2/2 300 mesh (Quantifoil Micro Tools) copper grids were glow-discharged with a 50:50 oxygen–hydrogen mixture in a Solarus 950 (Gatan) for 30 s. Grids were loaded into an EM GP2 plunge freezer (Leica), which was set to 4 °C and 95% humidity, and a 3-μl droplet of the sample was added. The sample was subsequently blotted for 3 s, 3.5 s or 4 s, followed immediately by plunge freezing in liquid ethane at −184 °C. Grids were mounted in AutoGrid assemblies.
Data were collected using a Krios G4 (Thermo Fisher Scientific) transmission electron microscope operating at 300 kV equipped with a K3 (Gatan) and a Biocontinuum GIF (Gatan) operating at a slit width of 20 eV. Image acquisition was performed with a 0° or 30° stage tilt. Movies were acquired at a pixel size of 0.4131 Å per pixel with a dose of ~50 e−/Å2 per movie using EPU (Thermo Fisher Scientific). Defocus values were set to cycle between 0.5 μm and 2.5 μm. Data quality was monitored during data collection using cryoSPARC Live v4.4.
Complete data processing was performed using cryoSPARC v4.5 with only the tilted data. Patch motion correction, dose-fractionated weighting and patch contrast transfer function estimation were carried out with default parameters. Blob picking was used to pick particles for the first round. High-quality two-dimensional (2D) classes, after several rounds of 2D classification, were used as templates for template-based particle picking. To clean up the data, extracted particles were classified in 2D for as many rounds as necessary. Ab initio volumes were determined with five classes, followed by heterogeneous, homogeneous and nonuniform refinement. Two rounds of global and local contrast transfer function refinement, reference motion correction and nonuniform refinement were carried out for the best class (Extended Data Fig. 3). No symmetry was imposed during refinement. The final reconstructed map is at 2.0-Å resolution (Extended Data Fig. 4). The local resolution of the final reconstruction was calculated in cryoSPARC and displayed in ChimeraX (Extended Data Fig. 4).
Map output by cryoSPARC nonuniform refinement was sharpened by PHENIX.auto_sharpen. The M. smegmatis ribosome structure (PDB 5O61) was docked into the sharpened map in ChimeraX and then refined by molecular dynamics using the ISOLDE plugin. Cycles of manual model building in COOT v0.9, followed by real-space refinement using PHENIX.real_space_refine, were repeated many times until no noticeable improvement could be observed. MolProbity was used for model validation.
PK and metabolic identification in mouse, rat and dog
Animals and dose administration for PK studies
Eight- to ten-week-old male C57BL/6 mice (approximately 25 g) and 12- to 14-week-old male and female Wistar Han rats (272−356 g for male, 220−230 g for female) were purchased from Charles River Laboratories. Male Beagle dogs (1,015 kg) were purchased from Marshall BioResources. All animals used in the low-dose intravenous/oral dose PK studies were fasted overnight before dosing, with water provided ad libitum. Male rats used for high-dose studies were also fasted before dosing. Additional male and female rats and male dogs used for high oral dose studies were fed before dosing.
Mice
MK-7762 was administered intravenously or orally (n = 3) to fasted male mice at 2 mg per kg body weight (1 ml per kg body weight) or 10 mg per kg body weight (10 ml per kg body weight), respectively, in DMSO:propylene glycol:water (20:60:20). Blood (10 μl) was collected via tail vein before dosing and at 0.08 h, 0.25 h, 0.5 h, 1 h, 2 h, 4 h, 7 h and 24 h after dosing for the intravenous arm, and before dosing and at 0.25 h, 0.5 h, 1 h, 2 h, 4 h, 7 h and 24 h after dosing for the oral arm. Three volumes of sodium citrate were added to the whole blood in matrix bullet tubes, vortexed, and then frozen immediately and stored at −70 °C until analysis.
Rats
MK-7762 was administered intravenously to fasted male rats via a jugular cannula at 2 mg per kg body weight (1 ml per kg body weight) in 30% Captisol (n = 3). Blood was collected before dosing and at 0.03h, 0.13 h, 0.25 h, 0.5 h, 1 h, 2 h, 4 h, 7 h, 12 h, 18 h and 24 h after dosing into tripotassium ethylenediaminetetraacetic acid (K3EDTA) tubes. The blood was centrifuged to obtain plasma. Plasma samples were frozen immediately and stored at −70 °C until analysis. For the low-dose oral studies, MK-7762 was administered to fasted male rats at 5 mg per kg body weight in 10% Tween 80 or at 10 mg per kg body weight in 0.5% methyl cellulose (MC) with a dosing volume of 5 ml per kg body weight (n = 3). Blood was collected before dosing and at 0.25 h, 0.5 h, 1 h, 2 h, 4 h, 7 h, 12 h (5 mg per kg body weight arm only), 18 h and 24 h after dosing into K3EDTA tubes. The blood was centrifuged to obtain plasma and processed as described above. For the high-dose oral studies, MK-7762 was administered to fasted male rats at 100 mg per kg body weight, 500 mg per kg body weight or 1,000 mg per kg body weight in 10% Tween 80, with a dosing volume of 5 ml per kg body weight (n = 3). Blood (0.25 ml) was collected before dosing and at 0.25 h, 0.5 h, 1 h, 2 h, 4 h, 7 h, 12 h, 18 h and 24 h after dosing into K3EDTA tubes. The blood was centrifuged to obtain plasma and processed as described above. MK-7762 was also administered to fed male and female rats at 50 mg per kg body weight or 1,000 mg per kg body weight in 10% Tween 80, with a dosing volume of 5 ml per kg body weight (n = 3). Blood was collected before the dose and at 0.25 h, 0.5 h, 1 h, 2 h, 4 h, 7 h, 12 h, 18 h, 24 h and 48 h after dosing into K3EDTA tubes. The blood was centrifuged to obtain plasma and processed as described above. Urine samples were also collected at 0−24 h and 24−48 h after the dose and stored at −70 °C until processing.
Dogs
MK-7762 was administered intravenously to fasted male dogs (n = 3) via a saphenous/cephalic vein catheter at 1 ml per kg body weight in 30% Captisol solution to achieve the target dose of 1 mg per kg body weight. Blood was collected before dosing and at 0.03 h, 0.13 h, 0.25 h, 0.5 h, 1 h, 2 h, 4 h, 6 h and 24 h after dosing into K3EDTA tubes. The blood was centrifuged to obtain plasma and processed as described above. For the low-dose oral studies, MK-7762 was administered to fasted male dogs at 2 mg per kg body weight in 10% Tween 80 or at 2 mg and 10 mg per kg body weight in 0.5% MC with a dosing volume of 5 ml per kg body weight (n = 3). Blood was collected before dosing and at 0.25 h, 0.5 h, 1 h, 2 h, 4 h, 6 h and 24 h after dosing into K3EDTA tubes. The blood was centrifuged to obtain plasma and processed as described above. For the additional 10 mg per kg body weight and high-dose oral studies, MK-7762 was administered to fed male dogs at 10 mg, 30 mg and 100 mg per kg body weight, or 200 mg per kg body weight in 10% Tween 80, with a dosing volume of 5 ml per kg body weight (n = 3). Blood was collected before the dose and at 0.25 h, 0.5 h, 1 h, 2 h, 4 h, 6 h and 24 h after the dose into K3EDTA tubes. The blood was centrifuged to obtain plasma and processed as described above.
Animals and dose administration for metabolite identification
MK-7762 was administered orally to two fasted male WH rats (360−400 g) at 5 ml per kg body weight (10 mg per kg body weight) in 10% Tween 80. Blood was collected at 4 h and 24 h after dosing via cardiac puncture. Plasma was obtained by centrifugation. Urine was collected into pre-tared containers for up to 24 h after dosing from one of the rats. All samples were stored at −70 °C until processing.
MK-7762 was administered orally to a fasted male Beagle dog (11 kg) at 5 ml per kg body weight (10 mg per kg body weight) in 0.5% MC via gavage. Blood (1 ml) was collected at 4 h and 24 h after dosing into K3EDTA tubes. Plasma was obtained by centrifugation. Urine was collected into pre-tared containers for up to 24 h after the dose. All samples were stored at −70 °C until processing.
Sample processing for PK
Blood, plasma and urine samples were processed via protein precipitation extraction using a Hamilton Microlab STAR liquid handling system (Hamilton Robotics) and Microlab STAR software (version 4.1.1.3714). The supernatant was analyzed by liquid chromatography with LC–MS/MS.
Sample processing for metabolite identification
Aliquots (200 μl) of rat plasma samples at 4 h or 24 h were precipitated with an equal volume of 90% acetonitrile and 10% methanol. The samples were vortex mixed for 2 min and then centrifuged at 10,000 rpm for 10 min. The supernatants were transferred to glass vials for high-resolution mass spectrometry (HRMS) analysis. Aliquots (200 μl) of dog plasma samples at 4 h or 24 h were precipitated with two volumes of 90% acetonitrile and 10% methanol. The samples were vortex mixed for 1 min and then centrifuged at 10,000 rpm for 10 min. The supernatants were transferred to glass vials and then diluted at a 1:1 ratio with water containing 0.1% formic acid for HRMS analysis. An aliquot of the 0−24-h urine samples from a rat or a dog (200 μl) was centrifuged at 10,000 rpm for 10 min and then transferred to a glass vial for HRMS analysis.
LC–MS/MS analysis for PK
The concentrations of MK-7762 in the mouse blood, rat and dog plasma, and rat urine were determined by comparison to a calibration curve prepared in the corresponding matrix, using liquid chromatography separation followed by triple-quadrupole mass spectrometry detection. For each study and matrix, two calibration curves were prepared. The standards in the calibration curve for the PK studies had nominal values of 1 nM to 10,000 nM.
The LC–MS/MS system comprised a Thermo Transcend LX2 multiplexed UPLC, Thermo Dionez Ultimate 3000 RS pumps (Thermo Fisher Scientific) and an Applied Biosystems/MDS Sciex API4500, API5000, API 5500 or API 6500 triple-quadrupole mass spectrometer. Chromatographic separation of the analytes was achieved on a Waters XSELECT HSS TS XP column (5 cm × 2.1 mm × 2.5 μm) with gradient conditions and mobile phase A (100% water with 0.1% formic acid) and B (100% acetonitrile with 0.1% formic acid). The flow rate was held constant at 0.75 ml min−1.
Analyte response was measured by multiple reaction monitoring (MRM) of unique transitions using positive ion mode at m/z 420.1 → 388.0 or 295.9 for MK-7762, and m/z 281.3 → 193.1 for the internal standard imipramine.
LC–HRMS analysis for metabolite identification
Chromatographic separation of MK-7762 and its metabolites was conducted using an Acquity UPLC (Waters) with a Waters Acquity Xbridge BEH C18 column (2.1 mm × 10 cm, 1.7 μm) at 40 °C. The mobile phase A consisted of 0.1% formic acid in water and mobile phase B consisted of 0.1% formic acid in acetonitrile. The flow rate was held constant at 0.5 ml min−1.
The mass spectrometry analysis was conducted using an AB Sciex 6600 time of flight mass spectrometer (AB Sciex) equipped with an electrospray ionization source and operated in the positive-ionization mode. The automated calibration device system performed an external calibration every five samples. The Duo Spray ion source equipped with a stainless-steel electrode (100-μm internal diameter) was operated with the following mass spectrometry conditions: gas 1, nitrogen (50 psi); gas 2, nitrogen (55 psi); ion spray voltage, 5500; ion source temperature, 500 °C; curtain gas, nitrogen (30 psi); and collision energy, 5 eV. The mass spectrometer was operated in the SWATH acquisition mode where one complete cycle consists of a survey scan and 22 Q1 isolation scans covering a mass range of 100–1,000 m/z. The survey scan covered a mass range of 100 to 1,000 m/z with an accumulation time of 0.13 s. The Q1 isolation strategy covered a mass range of 100 to 1,000 m/z with a variable Dalton SWATH window for Q1 isolation (overlap 1 U). In each SWATH window, a collision energy of 35 eV with a spread of ±15 eV and an accumulation time of about 0.02 s in high-sensitivity mode were used. The total cycle time was 0.6 s. All mass spectrometry parameters were controlled by Analyst TF Software 1.7 from Sciex. Data processing was accomplished using Mass-MetaSite (version CLI 5.2.0-8 Mass 3.4.0 ×64) and interpretation was done in WebMetabase.
Calculation of PK parameters
PK parameters were calculated using non-compartmental methods in Watson. The area under the plasma concentration–time curve (AUC0−t) was calculated from the first time point (0 min) up to the last time point with a measurable drug concentration using the linear trapezoidal or linear/log-linear trapezoidal rule. The concentration at 0 h after intravenous administration was back-extrapolated using the first two time points. The remaining area under the plasma concentration–time curve (AUCt−∞) was estimated by dividing the observed concentration at the last time point by the elimination rate constant. This value was added to AUC0−t to estimate the AUC0−∞. The intravenous plasma clearance was calculated by dividing the dose by AUC0−∞. The terminal half-life of elimination was determined by unweighted linear regression analysis of the log-transformed data. The time points for determination of half-life were selected by visual inspection of the data. The volume of distribution (Vd,ss) was obtained from the product of plasma clearance and mean residence time (determined by dividing the area under the first moment curve by the area under the curve). The Cmax and the Tmax were obtained by inspection of the plasma concentration–time data. Absolute oral bioavailability was determined from dose-adjusted intravenous and oral AUC0−∞ ratios.
Murine efficacy models of acute and chronic TB infection
Data were analyzed in GraphPad Prism version 10.2 using a one-way ANOVA, and statistical details of these comparisons are shown in Supplementary Tables 8 and 9. Six animals per treatment group were used considering historical variability29. Mice were housed in containment caging in an Animal Biosafety Level 3 containment facility at 72 °F and 50% relative humidity with a 12-h light cycle.
BALB/c acute TB infection model
Six- to eight-week-old female specific-pathogen-free BALB/c mice (Jackson laboratories) were aerosol infected with a Glas-Col inhalation exposure system using previously calibrated frozen Mtb Erdman pFCA-LuxAB (Erdman-Lux) that was thawed and diluted before use as described30,31. The average bacterial load in lungs one day after low-dose aerosol was approximately 131 CFUs. Six infected mice were euthanized 7 days after infection as pretreatment controls. Ten mice were left untreated to serve as the study comparator. Drugs were prepared in weekly batches in 10% Tween 80/40% PEG400/50% water, and aliquots were held at 4 °C for daily use. Drugs were administered for 12 consecutive days by oral gavage in a volume of 0.2 ml per mouse once daily or twice daily, as indicated.
BALB/c chronic TB infection model
Six- to eight-week-old female specific-pathogen-free BALB/c mice (Jackson laboratories) were aerosol infected with a Glas-Col inhalation exposure system using previously calibrated frozen Mtb Erdman-Lux that was thawed and diluted before use32. The average lung bacterial load one day after low-dose aerosol was approximately 147 CFUs. Six infected mice were euthanized 28 days after infection as pretreatment controls. Eight mice were left untreated to serve as the study comparator. Drugs were prepared in weekly batches as above, and aliquots were held at 4 °C for daily use. Drugs were administered daily 7 days per week by oral gavage in a volume of 0.2 ml per mouse once daily.
Bacterial enumeration acute and chronic models
At given time points, organs were aseptically harvested from mice after a weekend drug-free holiday following the last day of dosing to allow drug clearance from tissues. Tissues were frozen in 7 ml Bertin Precellys tubes (CKmix50_7 mL P000939-LYSK0A). Tissues were thawed and homogenized (Precellys, Bertin Instruments) in 4.5 ml PBS plus 10% (wt/vol) bovine serum albumin (PBS-BSA). Portions of the homogenates from animals on treatment were serially diluted in PBS-BSA and plated for CFUs on 7H11-OADC agar (that is, Middlebrook 7H11 agar plates supplemented 0.2% (vol/vol) glycerol, 10% (vol/vol) oleic acid-albumin-dextrose-catalase (OADC) supplement, and 0.01 mg ml-1 cycloheximide, and 0.05 mg ml-1 carbenicillin) further supplemented with 0.4% (wt/vol) activated charcoal (7H11 charcoal agar) to help counteract drug carryover artifacts33,34. Plates were incubated for at least 21 days at 37 °C and for 6 weeks total to confirm all CFUs were quantified.
Lesion-penetration studies
Eight- to ten-week-old female specific-pathogen-free C3HeB/FeJ mice (Jackson laboratories) were aerosol infected with a Glas-Col inhalation exposure system to achieve approximately 75 CFUs deposited in lungs one day following infection with previously calibrated frozen Mtb Erdman (TMCC 107)34. Mice (n = 5 or 6 mice per study arm) were dosed starting 10 weeks after aerosol with MK-7762 or linezolid each at 100 mg per kg body weight, once daily. Drugs were prepared as described for the efficacy studies above. Treatment occurred on 5 of 7 days per week (Monday through Friday) for a total of 2.5 weeks to reach steady-state drug levels. Mice were euthanized, and plasma and tissues were collected at the indicated time points.
Whole blood was obtained via cardiac puncture and processed in plasma separator tubes (Becton, Dickinson and Co.) centrifuged at 3,750g for 2 min at 4 °C, aliquoted into microcentrifuge tubes and stored at −80 °C until analysis. Mice with pronounced lung pathology were selected to collect samples for spatial drug quantification by gravity-assisted LCM. Briefly, whole lung samples consisting of the cranial, medial and accessory lung lobes were collected on clear disposable base molds with the desired cutting surface in direct contact with the base of the tray (Fisher Scientific). Collection trays are then placed onto a prechilled 4-inch aluminum block in 2 inches of liquid nitrogen in a Styrofoam cooler and allow to sit covered for 10 min. Tissue trays containing frozen lobes were wrapped in foil squares, placed individually into labeled ziplock bags and immediately transferred onto dry ice. Samples were stored at −80 °C until analysis.
LCM
Twenty-five-micron-thick tissue sections were cut from C3HeB/FeJ mouse lung biopsy samples using a Leica CM 1860UV cryostat and thaw-mounted onto 1.4-µm-thick Leica PET-Membrane Frame Slides for LCM. Tissue sections were immediately stored in sealed containers at −80 °C. Adjacent 10-µm-thick tissue sections were thaw-mounted onto standard glass microscopy slides for H&E staining. Cellular, necrotic (caseum) and uninvolved lung lesion areas totaling 3 million µm2 were dissected from one to three serial lung biopsy tissue sections using a Leica LMD6 system set up within a Biosafety Level 3 facility. Areas of cellular and caseous lesions were identified optically from the brightfield image scan and by comparison to the adjacent H&E reference tissue. Pooled dissected lesion tissues were collected into 0.25-ml standard PCR tubes and immediately transferred to −80 °C. Processing of LCM samples was performed by adding 10 µl of each working standard solution to 2 µl of 1:26.7 diluted in PBS drug-free tissue homogenate to create standard curve and quality-control (QC) samples. MK-7762 was extracted from the calibration standard, QC, blank/control and LCM study samples by the addition of 50 µl of extract solvent containing imipramine. Extracts were sonicated for 10 min and centrifuged at 4,000 rpm for 5 min. Around 50 µl of supernatant was transferred to a 96-well plate and 50 µl of water was added for LC–MS/MS analysis.
Drug quantification in plasma and infected tissues by HPLC–MS/MS
Verapamil internal standard was purchased from Sigma-Aldrich. Drug-free K2EDTA plasma from BioIVT was used as a blank matrix to build standard curves. Neat 1 mg ml−1 DMSO stock for MK-7762 was serial diluted in 50/50 acetonitrile/water to create standard curves and QC spiking solutions. Spiked matrix standards and QC samples were created by adding 10 µl of spiking solutions to 90 µl of drug-free plasma and control tissue homogenate. Extraction was performed for standards, QC samples and study samples by adding 200 µl of a 1:1 acetonitrile–methanol mixture containing 10 ng ml−1 verapamil to 20 µl of plasma or homogenized tissue sample. One hundred microliters of extracts were diluted with 100 µl of water and vortexed for 2 min before injecting into the LC system.
LC–MS/MS analysis was performed on a Sciex Qtrap 6500+ triple-quadrupole mass spectrometer coupled to a Shimadzu Nexera X2 UHPLC system to quantify each drug in plasma. Chromatography was performed on an Agilent Zorbax SB-C8 column (2.1 × 30 mm; particle size, 3.5 µm) using a reverse-phase gradient elution with an aqueous mobile phase. Water with 0.1% formic acid was used for the aqueous mobile phase and 0.1% formic acid in acetonitrile for the organic mobile phase. MRM of precursor/fragment transitions in electrospray positive-ionization mode was used to quantify the analytes. MRM transition of 420.00/388.00 and 455.40/165.00 were used for MK-7762 and verapamil, respectively. Sample analysis was accepted if the concentrations of the QC samples were within 20% of the nominal concentration. Data processing was performed using Analyst software (version 1.6.3; Sciex).
Statistics and reproducibility
No statistical method was used to predetermine sample size. For the efficacy studies, sample size was chosen based on prior studies29. No data were excluded from the analyses. One-way ANOVA followed by Tukey’s multiple-comparison test was performed in GraphPad Prism (v10.4.1) for Windows (GraphPad Software; https://www.graphpad.com/). Data distribution was assumed to be normal, but this was not formally tested. The experiments were not randomized. The investigators were not blinded to allocation during experiments and outcome assessment.
Reporting summary
Further information on research design is available in the Nature Portfolio Reporting Summary linked to this article.
